The DSC-1000 Differential Scanning Calorimeter delivers high-precision thermal analysis with exceptional sensitivity and repeatability, making it ideal for evaluating material transitions, stability, and thermal properties across research, quality control, and industrial applications.
Key Specifications
Max Temperature
1200°C
Heating Rate
0.1–100°C/min
DSC Sensitivity
0.01 mW
Touch Display
7" Color LCD
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Introduction
DSC-1000 is one of the most accurate DSC series products launched by the company. The sensor is made of imported material E-pair, which has high accuracy, high sensitivity and good repeatability. The signal acquisition circuit has shielding protection, strong anti-interference, and extremely high baseline stability and repeatability.
DSC-1000 Differential Scanning Calorimeter can be used to test glass transition temperature, phase transition temperature, melting point, enthalpy value, curing temperature, product stability, oxidation induction period, etc. It is competent in the research of pipes, polymers, chemicals, food, medical treatment and many other fields, and its products serve universities, enterprises, third-party measurement and quality inspection units, with a wide range of applications to meet the testing needs of various industries.
Key Features
- Imported E-Pair Sensor delivers high accuracy, high sensitivity, and excellent repeatability for precise thermal measurements.
- Advanced Shielding Protection minimizes external interference while providing outstanding baseline stability and measurement reliability.
- Comprehensive Thermal Analysis supports glass transition temperature, phase transition, melting point, enthalpy, curing temperature, oxidation induction period, and product stability analysis.
- Automatic Program Control features a 7-inch LCD touchscreen with programmable heating, constant temperature, cooling, and automatic atmosphere switching for efficient operation.
Technical Parameters
| Temperature Range | Room temperature ~ 1200℃ |
| Temperature Resolution | 0.01℃ |
| Temperature Fluctuation | ±0.1℃ |
| Temperature Repeatability | ±0.1℃ |
| Heating Rate | 0.1～100℃/min |
| Incubation Time | Program setting ≤24h |
| Temperature Control | Heating up, constant temperature, cooling down (Full automatic program control) |
| DSC Range | 0～±600mW |
| DSC Resolution | 0.01uW |
| DSC Sensitivity | 0.01mW |
| Working Power Supply | AC220V/50Hz Or customized |
| Atmosphere Control Gas | Nitrogen, Oxygen (Program setting/automatic switching) |
| Gas Flow | 0–200mL/min |
| Gas Pressure | 0.5MPa |
| Display Mode | 24bit color, 7-inch LCD touch screen display |
| Data Interface | Standard USB interface |
| Parameter Standard | Equipped with reference materials (tin), The user can correct the temperature by himself |
| Temperature Monitoring | The instrument has multiple sets of thermocouples: one group measures sample temperature, one group measures furnace temperature, and one group measures the internal ambient temperature |
Applications
Polymer & Plastics
The DSC-1000 Differential Scanning Calorimeter is widely used for thermal analysis of polymer and plastic materials. It can analyze glass transition temperature, melting point, phase transition, oxidation induction period, curing behavior, and thermal stability, making it suitable for quality control, product development, and material research.
Chemical, Food & Medical
The instrument is suitable for evaluating thermal properties, product stability, curing characteristics, and material performance of chemicals, food products, and medical materials, providing reliable thermal analysis for research and industrial applications.
Universities, Enterprises & Testing Laboratories
The DSC-1000 is widely used in universities, enterprise research centers, third-party testing laboratories, and quality inspection institutions for thermal analysis, material characterization, quality control, and scientific research.
