Oxygen Index Tester

Name: Oxygen Index Tester
Brand: TestShine

Oxygen Index Tester for Evaluating Material Combustibility

1 / 2

TS-LOI1

Oxygen Index Tester

Laboratory instrument for determining the minimum oxygen concentration required to sustain material combustion.

Key Specifications

Measurement Range

0–100% Oxygen

Resolution

0.1%

Accuracy

±0.2%

Response Time

<300 ms

Oxygen Index TesterCombustibility TestingOxygen SensorPlastic Testing

Request a Quote Request Sample Testing

Global Shipping

50+ countries

2-Year Warranty

Parts & service

Expert Support

Dedicated team

Have a question about this instrument?

Talk to an expert

Product Information

The TS-LOI1 is designed to evaluate the combustibility of a material through oxygen concentration. It tells the user the minimum oxygen concentration needed for the material to keep burning.

Key Features

Fitted with a Paramagnetic type oxygen sensor of English Servomex origin, with an accuracy of up to +/-0.1%.
Compared with a traditional electrochemical sensor, this sensor needs no replacement oxygen cell, which gives it a longer service life, higher accuracy and a faster response time.
Two Mass Flow Controllers (MFC) regulate the mixing ratio of N2 and O2.
Equipped with a high-temperature quartz glass tank.

Technical Parameters

Parameter	Specification
Oxygen Concentration Measurement Range	0–100%
Resolution	0.1%
Accuracy	±0.2%
Response Time	<300 ms
Oxygen Stability Time	<30 s
Oxygen Concentration Sensor	England Servomex Paramagnetic Type Oxygen Sensor, Accuracy: ±0.1%

Applications

Plastic Materials: Evaluation of the minimum oxygen concentration required to sustain combustion in plastic materials.
Polymer Materials: Assessment of the combustion characteristics of polymer materials using oxygen concentration.
Material Combustibility Testing: Determination of the oxygen concentration needed for a material to continue burning.
Research and Quality Control: Evaluation of material combustibility for laboratory research and quality control.
