The TS-WVPA3 Water Vapor Transmission Rate (WVTR) Analyzer uses the gravimetric (weight-loss) test principle for water vapor transmission testing of films, sheets, paper, packaging, and comparable materials.
Key Specifications
Test Range
0.1~10000 g/(m2·24h)
Test Precision
0.0001 g/(m2·24h)
Temperature Range
15~55℃
Humidity Range
Relative humidity 90%RH
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Introduction
The TS-WVPA3 Water Vapor Transmission Rate (WVTR) Tester is built on the gravimetric (weight-loss) test method and complies with the requirements of GB/T 1037, ASTM E96, and other related standards. It is designed to evaluate the water vapor permeability of films, sheets, papers, packaging, and comparable materials, making it a practical solution for the food, pharmaceutical, medical device, daily chemical, and photovoltaic electronics industries. With a wide detection range and efficient measurement performance, the instrument supports water vapor transmittance testing across high-, medium-, and low-barrier materials.
Key Features
High-Precision Load Cell
The analyzer is fitted with a high-precision weighing sensor that delivers stable, efficient weighing performance, achieving a measurement resolution of up to 0.0001 g/(m2·24h). A semiconductor-based temperature stabilizer automatically regulates chamber temperature, maintaining a control accuracy of 0.1℃.
High Throughput, Wide Testing Range, and Broad Applicability
Three independent test chambers, each generating its own data set, allow simultaneous multi-sample testing and improve overall testing efficiency. A wide measurement range of 0.1~10000 g/(m2·24h) accommodates high-, medium-, and low-barrier materials alike, and with customized fixtures, the instrument can also be used to test the water vapor transmission of bottles, bags, bowls, and other finished packaging items.
Refined Design, Simple Operation, Real-Time Curve Display
The housing is shaped with ergonomics and technical aesthetics in mind, featuring a finely finished 3D-printed shell with clean lines and a modern appearance. Operation is fully automated, covering one-key test initiation, automatic result judgment, and automatic shutdown. The display presents four live curves in real time — transmittance versus time, temperature versus time, humidity versus time, and weight versus time — with an option to preview or hide individual curves.
Technical Parameters
| Item | Specification |
| Test range | 0.1~10000 g/(m2·24h) |
| Test precision | 0.0001 g/(m2·24h) |
| Temperature range | 15~55℃ |
| Temperature accuracy | ±0.1℃ |
| Humidity range | ≤10%RH |
| Humidity accuracy | ±2%RH |
| Test area | 50.24 cm2 |
| Sample size | Φ90 mm |
| Sample thickness | ≤3mm |
| Number of test sample | 3 pieces |
| Power | 1300 W |
| Power supply | AC 220 V，50 Hz |
| Dimension | 1150×545×315mm |
| Weight | 66kg |
Applications
Film
Water vapor permeability testing of plastic films (PP, PET, PE, PVC, BOPP, CPP, and similar materials), plastic composite films, paper-plastic composite films, metallized composite films, co-extruded films, aluminum-coated films, and degradable packaging films (PLA, PBAT, PBS, and similar materials).
Sheet
Water vapor permeability testing of rigid pharmaceutical blister sheet (PP, PVC, PTP, and similar materials), metal composite sheet, rubber sheet, and other sheet-form materials.
Paper, Paperboard and Composite Materials
Water vapor permeability testing of coated paper, silicone paper, aluminized cigarette paper, paper-aluminum-plastic composite sheet, and paperboard.
