Product Information

The TS-HS2 Lid Film Heat Seal Tester is engineered to accurately evaluate the heat sealing performance of lidding films used on food and pharmaceutical packaging, including jelly cups, yogurt cups, coffee capsules, instant noodle containers, lunch boxes, and medical blister packaging. Because heat sealing behavior varies considerably between materials, the instrument measures critical sealing parameters — temperature, time, and pressure — to help manufacturers and quality teams pinpoint the optimal sealing conditions for each packaging material, supporting consistent seal integrity and product quality.

Key Features

Convenient Pull-Out Sample Loading

The lower tray uses a double-layer stacking design that pulls out for sample loading, keeping hands clear of the upper sealing knife for a more convenient and safer testing experience.

High-Precision Temperature Control

A high-precision temperature sensor combined with PID-based temperature control delivers a control accuracy of ±1℃, ensuring excellent stability and a very low failure rate.

Flexible Test Modes

Manual and automatic testing modes can be freely selected. Automatic mode saves time by repeating the heat sealing cycle automatically, while manual mode uses a dedicated foot switch — pressing the switch brings the sealing knives together for safe, straightforward operation.

Advanced Pneumatic Drive System

The drive system comprises a pressure gauge, a pressure regulating valve, and a cylinder. Once compressed air is supplied, pressure can be finely adjusted and accurately locked via the regulating valve, allowing the heat sealing fixture to be pneumatically driven for efficient, convenient operation.

Technical Parameters

Applications

The TS-HS2 is widely used for heat seal testing of lidding films on packaging formats such as jelly cups, yogurt cups, coffee capsules, and medical blister packs.
