Electronic Tensile Tester
Single-Column Electronic Tensile Tester for Material and Packaging Testing
1 / 2Electronic Tensile Tester
The TS-ET4 is a single-column electronic tensile tester designed for reliable mechanical performance testing of a wide range of metallic and non-metallic materials. Equipped with high-precision sensors, automated control, dedicated testing software, and real-time test curve display, it provides accurate force measurement, stable loading, and convenient test report retrieval. Its compact table-type structure, comprehensive safety protection, and versatile testing capabilities make it suitable for quality control, research, teaching, and laboratory applications.
Key Specifications
Test Force Range
0 – 300 N
Test Accuracy
±0.5% FS
Test Speed
0 – 500 mm/min
Sampling Rate
100 readings/s
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-ET4 is a widely adopted single-column electronic tensile tester engineered for reliable mechanical performance testing, developed in line with ASTM and other relevant international standards to meet the evolving needs of the testing industry. The instrument is built around high-precision sensors that deliver excellent force measurement accuracy, stable and consistent loading, and a long operating service life. An LCD display paired with dedicated professional software presents test curve data in real time and allows convenient, on-screen retrieval of test reports, making everyday laboratory testing fast and efficient. The tester operates fully automatically through an integrated control and measurement unit, and is equipped with comprehensive safety features, including travel-limit protection, overload protection, and an emergency stop function.
Designed for versatility, the TS-ET4 is suitable for tensile, peel, heat-seal, tear, and other mechanical performance tests on a broad range of metallic and non-metallic materials. It satisfies the testing requirements set out by national technical supervision authorities and is widely used by plastic film, food, and pharmaceutical manufacturers for product quality control, as well as by testing institutions and university research and teaching laboratories.
Key Features
Elegant and Convenient Body Design
The table-type column structure offers a compact, refined appearance and allows the operator to work comfortably and naturally while seated.
Multi-Function, High-Efficiency Testing
The tester performs stretching, peeling, heat-sealing, tearing, and other tests, with multi-parameter adjustment of width, speed, thickness, and clamping distance. A high sampling rate of 100 readings per second ensures accurate and reliable test data.
Safe, High-End Mechanical Structure
Three-level safety protection and an installed emergency stop switch help ensure safe operation. Imported core components provide high precision and a long service life, while the LCD screen displays test data and working status.
Technical Parameters
| Parameter | Specification |
| Test Force Range | 0~300 N (Option 0~500 N), 1250% Elongation |
| Test Accuracy | Within ±0.5 %FS of the displayed value (Level 1) |
| Test Speed | 0~500 mm/min (infinitely variable speeds) |
| Displacement Accuracy | Within ±0.5% of the displayed value |
| Test Width Range | 30 mm (can be customized for 50 mm and 60 mm) |
| Effective Test Distance | 750 mm (can be customized for 1000 mm) |
| Instrument Size | L×W×H：600 mm×500 mm×1300 mm |
| Weight | 65 kg |
| Power | AC 220 V，50 Hz |
Applications
Plastic Film
Suited for tensile, peel, heat-seal, and tear performance testing of plastic films, composite materials, flexible packaging materials, tapes, and related products.
Composite Film Bag
Suited for tensile, peel, heat-seal, and tear performance testing of composite films, co-extrusion films, composite bags, retort pouches, aluminum-plastic composite bags, and related products.
Paper
Suited for tensile, peel, heat-seal, and tear performance testing of paper, kraft paper, facial tissue, toilet paper, and related products.
Medical Patch
Suited for tensile, peel, heat-seal, and tear performance testing of medical cold compresses, plasters, and related products.
