Coefficient of Friction Tester
Coefficient of Friction Tester
1 / 2Coefficient of Friction Tester
Advanced coefficient of friction tester designed to evaluate the static and dynamic friction properties of films, foils, rubber, ceramics, and other materials, supporting accurate surface smoothness and sliding performance analysis.
Key Specifications
COF Test Range
0.001 – 0.999
Force Range
0 – 10 N
Sliding Speed
0 – 500 mm/min
Resolution
0.001
Global Shipping
50+ countries
2-Year Warranty
Parts & service
Expert Support
Dedicated team
Have a question about this instrument?
Talk to an expertProduct Information
The TS-CFT1 coefficient of friction tester is engineered to evaluate how easily two surfaces slide against one another, giving manufacturers a reliable way to assess film smoothness, ease of opening and overall material uniformity. Its design draws on GB, ISO and ASTM testing standards as well as extensive input from real world production requirements, resulting in an instrument that translates directly into better process control on the production line.
The instrument measures static friction coefficient, dynamic friction coefficient and peel strength across a wide range of materials, including plastic films, composite films, aluminum foils, aluminized films, plates, rubber and ceramics, making it a versatile addition to any quality control laboratory.
Key Features
- The force sensor is straightforward to calibrate, with a dedicated standard block enabling fast and convenient calibration.
- An integrated liquid crystal display presents the static and dynamic friction coefficients in real time.
- The accompanying control software offers a clean, intuitive interface that is easy to operate.
Technical Parameters
| Parameter | Specification |
| COF test range | 0.001~0.999 |
| Force range | 0~10 N |
| Resolution | 0.001 |
| Measurement accuracy | ±0.5％FS |
| Sliding speed | 0~500 mm/min (Stepless speed adjustment) |
| Stroke | 0-150 mm |
| Sample thickness | ≤2 mm |
| Slider size | 63 mm×63 mm (if American standard, 63.5 x 63.5 mm) |
| Slider Weight | 200 g±2 g |
| Work platform size | 200 mm×470 mm |
| Temperature range | Room temperature~75℃（optional） |
| Instrument size | 470 mm×300 mm×300 mm |
| Power | 100 W |
| Power supply | AC 220 V, 50 Hz |
| Weight | 14 kg |
Applications
- Quality control testing of plastic films, composite films, aluminum foils, and aluminized films for surface friction and sliding characteristics.
- Evaluation of film smoothness and ease of opening in packaging materials.
- Friction coefficient testing of plates, rubber, and ceramics to evaluate their sliding behavior.
- Material uniformity and process-control evaluation in manufacturing and quality-control laboratories.
